Automatic Chips Frying Machine , Vegetable / Fruit Vacuum Fryer SS 304 Material
Vacuum frying machine has integrated design. Frying, deoiling, dewatering and oil filter can finish coutinously under vacuum condition. The materials have less oil and water elements. And under low pressure, this fryer can avoid oxidation harm and make food form loose porous structure.
a.) Consultation service before, during, and after sales;
b.) Project planning and design service;
c.) Debugging of equipment until everything is functional;
d.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;
e.) Training of equipment maintenance and operating personally;
d.) New production techniques and formulas;
e.) Provide 1 year complete warranty and life-time maintenance service.
- The Low Temperature Vacuum Fryer Has the Following Advantages
1. The heating speed is fast, only need 8-13mins to reach required temperature. The oil cycle area is 35-40m³.
2. Fully automatic computer control from feeding to de-oiling. 1 person can operate 5 sets.
3. Equipped most advanced vacuum pump, including our own design. The vacuum degree can be maintain -0.098mpa all the time. The noise can be controlled below 60db.
4. The de-oiling speed is 300r/min. It also can be changed according to different products.
5. Reasonable oil inlet design keep the even oil washing. The product has good color.
6. Quality: we will do pressure test before delivered.
7. After sales service: our engineer will go to your place for installation and traning.
8. Oil filter tank design: fully automatic production line is realized.
| Model | VF-LY50 | VF-LY100 | VF-LY200 |
| Basket Size | dia600*500 | dia750*530 | dia1200*600 |
| L*W*H | 1400*3500*2500 | 1800*4000*2900 | 2500*4500*3100 |
| Vacuum Degree | -0.095mpa~-0.098mpa |
| Steam Pressure | 0.4~0.8mpa (adjustable) |
| Working temperature | 75-110℃ | 75-110℃ | 75-110℃ |
| Pump Power | 3kw | 5.5kw | 7.5kw |
| Vacuum Pump Power | 7.5kw | 11kw | 15kw |
| Motor Power | 3kw |
| Capacity | 50kg/batch | 100kg/batch | 200kg/batch |
| Total Power | 15kw | 22kw | 30kw |
| Feeding | 30~50kg/time | 80~100kg/time | 170~200kg/time |
| Raw Material Input | 30kg-50kg | 80kg-100kg | 170kg-200kg
|
- Vacuum Frying Machine Core Components of Liuyi Machinery
- Oil storage tank
It is for oil storage before frying. The oil will be heated in it firstly. During frying, the oil will be cycled between oil storage tank and frying pot.
- PLC control system
Brand: Mitsubishi
It is control the whole machine.
This make the machine operate fully automatically. No need to manual during processing.
- Touch screen
Brand: Mitsubishi
The new type is connect directly with the machine body, not separate part.
It is easy to understand and operate.
- Electrical Components
Brand: Schneider
It mainly includes dis-connector, frequency converter and thermal overload relay.
Catalog for Automatic Vacuum Frying Machine.pdf
